P5000

Highlights

The P5000 Plow can be retrofitted to many existing chassis and plow hitches, including DIN, hands-free, hustings, J-hook and pin type hitches. It is designed to provide a fully reversible left and right angle up to 32 degrees.

  • The moldboard height is 50 inches, with a 65, 75 and 85 degree adjustable moldboard angle in both straight and flared configurations

  • Available in 14, 16, 18, 20, 22, and 24-foot lengths

  • A front mounted rubber deflector is standard to reduce overspray for optimum operator visibility

  • Substantial fuel savings with 500 pounds less weight than competitors

Equipment

  • Widths Available:

    14'

  • Height:

    50" moldboard height

  • Max Angle:

    Up to 32 degrees

  • Mode of Angle:

    Moldboard oscillation to follow angled (sway) pavement independent of chassis

  • Trip Mechanism:

    Lift, and swing uses chassis hydraulic system

  • Positions:

    Fully reversible angle left and right up to 32 degrees

  • Mount:

    DIN hitch standard

  • Standard Accessories :
